Size |
NPS 1/2″- 36″ and from 1 13/16″ to 13 5/8″ |
|
Pressure |
Class 150 – 2500 and from 2000Psi to 15000Psi |
|
Material |
WCB, LCB, CF8/CF8M, CF3/CF3M, A105, LF2, F304/F304L, F316/F316L, F347, F51, F53, F55, F60, INC 625, INC 825, INC718 |
|
Design & Manufacture Std. |
API 6D, API 6DSS, API 6A, BS 1868, ASME B16.34 |
|
Face to Face Std. |
API 6D, API 6A, ASME B16.10,DIN 3202 |
|
End Connection Std. |
ASME B16.11, ASME B1.20.1, ASME B16.5,ASME B16.47, DIN2543-2550,ASME B16.25, Hubs, Norsok, Pups |
|
Test standard |
ISO5208, API 6D, API 6DSS, API6A, API 598 |
|
Structure Type |
Regular Pattern, Pressure Sealed Pattern, Damping Pattern , Full bore |
|
Size |
NPS 2″- 36″ |
|
Pressure |
Class 150 – 2500 |
|
Material |
WCB, LCB, CF8/CF8M, CF3/CF3M, A105, LF2, F304/F304L, F316/F316L, F347, F51, F53, F55, F60, INC 625, INC 825, INC718 |
|
Design & Manufacture Std. |
API 6D, API 6DSS, ASME B16.34 |
|
Face to Face Std. |
API 6D, ASME B16.10,DIN 3202 |
|
End Connection Std. |
ASME B16.11, ASME B1.20.1, ASME B16.5,ASME B16.47, ASME B16.25, Hubs, Norsok, Pups |
|
Test standard |
ISO5208, API 6D, API 6DSS, API 598 |
|
Structure Type |
Regular Pattern non slam |
|
Size |
NPS 1/2″- 36″ |
|
Pressure |
Class 150 – 2500 |
|
Material |
WCB, LCB, CF8/CF8M, CF3/CF3M, A105, LF2, F304/F304L, F316/F316L, F347, F51, F53, F55, F60, INC 625, INC 825, INC718 |
|
Design & Manufacture Std. |
API 6D, API 6DSS, ASME B16.34 |
|
Face to Face Std. |
API 6D, ASME B16.10 |
|
End Connection Std. |
ASME B16.11, ASME B1.20.1, ASME B16.5,ASME B16.47, ASME B16.25, Hubs, Norsok, Pups |
|
Test standard |
ISO5208, API 6D, API 6DSS, API 598 |
|
Structure Type |
Regular Pattern non slam |
|
Size |
NPS 1/2″- 36″ |
|
Pressure |
Class 150 – 2500 |
|
Material |
WCB, LCB, CF8/CF8M, CF3/CF3M, A105, LF2, F304/F304L, F316/F316L, F347, F51, F53, F55, F60, INC 625, INC 825, INC718 |
|
Design & Manufacture Std. |
API 6D, API 6DSS, ASME B16.34 |
|
Face to Face Std. |
API 6D, ASME B16.10 |
|
End Connection Std. |
ASME B16.11, ASME B1.20.1, ASME B16.5,ASME B16.47, ASME B16.25, Hubs, Norsok, Pups |
|
Test standard |
ISO5208, API 6D, API 6DSS, API 598 |
|
Structure Type |
Regular Pattern non slam, Isolation and control |
